JI Series

Inflatable Jacks

Category:
  • Non-inflated jacks are less than 25,4 mm thick, making lifting tasks in small spaces seem routine.
  • Constructed of non-conducting, high quality rubber material with multi-layer aramid fiber reinforcement.
  • The top and bottom surface of the jack has a skid resistant, interlocking pattern to assist in alignment of two jacks being used together.
  • The jacks can be used at ambient temperatures of -20°C to + 50°C.
  • The controller, shut-off and air hoses are all equipped with an industrial interchange style quick-disconnect air coupler. Female half coupler bodies have a locking collar to help the operator avoid accidentally disconnecting the jack while under load.
Model No. Capacity Lifting Height Air Pressure Air Volume Dimensions Weight
  (Tons) (mm) (BAR) (l) Length Width Thickness (Kg)
JI5 5 160 8 42 300 300 25 2.4
JI10 10 210 8 86 380 380 25 4.2
JI15 15 250 8 152 450 450 25 6
JI20 20 300 8 296 550 550 25 8.5
JI30 30 340 8 416 610 610 25 11.5
JI45 45 420 8 921 780 780 27 19.1
JI55 55 470 8 1305 870 870 27 23.9
